After receiving all the components, I finished soldering the main board.
Drilling the perfboard with the step drill bit proved to be more challenging than I expected, and ended up having misaligned holes. A couple of days after, I got the Fostner bit and drilled the holes easily.
Now I'm currently gluing the dummy components to the perfboard. I need to get some blue resistors, capacitors in the correct form factor, and wooden spacers to glue the perfboard to the IN-14 board and finally put everything together.
Sunday, May 27, 2018
Wednesday, May 23, 2018
Of Nixies and perfboards.
Today I received the 12 Nixie tubes I ordered.
I tried using a laser engraver to cut out the holes from the perfboard, but it didn't do much more than just burn the shapes a little bit.
I ordered a a step drill bit and a fortsner bit, as suggested by a friend, to drill the holes. After I finish the perfboard, I can put the dummy parts on it, glue it to the IN-14 board, and finally solder the Nixies.
Buying Soviet electronics is not complete without Cyrillic in the packaging.
The tubes arrived in a good state, but have short leads and I had to remove solder from most of them.I tried using a laser engraver to cut out the holes from the perfboard, but it didn't do much more than just burn the shapes a little bit.
I ordered a a step drill bit and a fortsner bit, as suggested by a friend, to drill the holes. After I finish the perfboard, I can put the dummy parts on it, glue it to the IN-14 board, and finally solder the Nixies.
Sunday, May 20, 2018
Soldering the IN-14 board.
The flux pen worked marvels to remove the solder bridges from the SMDs and to solder them properly.
I also soldered all the pin headers and current-limiting resistors on the board.
Now I only need a few components to finish the main board, the Nixie tubes, and to do the perfboard with the dummy components and I can test if it works.
I also soldered all the pin headers and current-limiting resistors on the board.
Now I only need a few components to finish the main board, the Nixie tubes, and to do the perfboard with the dummy components and I can test if it works.
Saturday, May 19, 2018
Continuing soldering the main board.
I fixed J1 being soldered on the wrong side of the board and soldered the HVPS that arrived today. It turns out that they no longer include the 330ยตF capacitor with it, so I'll need to get one.
Friday, May 18, 2018
Soldering
Soldering SMDs is horrible.
I tried to fix the solder bridges to no avail. I'll fix it when I get a flux pen. I then proceeded to solder the components I have to the main board.
Note that the pin sockets (J1) are soldered the other way around.
I tried to fix the solder bridges to no avail. I'll fix it when I get a flux pen. I then proceeded to solder the components I have to the main board.
Note that the pin sockets (J1) are soldered the other way around.
Wednesday, May 16, 2018
